RPG Chassis System — Rapid. Precision. Gun.

RPG Chassis System

Unleash Precision. Dominate performance. The RPG (Rapid Precision Gun) Chassis System turns your Ruger® 10/22® into a highly modular, competition-ready platform.

Built to adapt, engineered for rigidity, designed for you to build exactly what you need.

The RPG Chassis System combines the strength of a one-piece aluminum body with the flexibility of modular forends, AR-style grip compatibility, and AR-15 buffer-tube buttstock options.

Built in the USA, designed and assembled in Evanston, Wyoming

Spotlight Feature

Simple, effective, and built for your shooting style.

The RPG provides a rigid, free-floating platform with integrated ARCA rails and modular forend choices.

Whether you’re running NRL22, PRS22, or building a dedicated trainer, the RPG delivers precision you can afford.

HOW IT WORKS: MODULAR BY DESIGN

Choose Your Inlet

Currently available:

Ruger® 10/22® footprint
Coming soon: CZ457, Bergara BMR, Remington 700 clones (precision & hunter inlets)

Select Your Forend

Comp Forend (16″): Full-length ARCA rail, M-LOK slots, accepts TRS Glide Bar brass weights for balance tuning

HR1 + Adapter (13″ or 16″): Based on our proven HR1 handguard for Accuracy International rifles. Integrated ARCA rail, M-LOK slots, knurled bottom, and your choice of compact 13″ or extended 16″

Finish Your Build

Buttstock: Any AR-15 buffer tube and stock

Grip: Any non-beavertail AR-style pistol grip

RPG: KEY FEATURES

MODULAR INLET & FOREND

CONE STEEL SET SCREW SYSTEM — SECOND PONIT OF CONTACT Deployed through the center of the buttstock tube, this set screw applies pressure to the trigger group, giving a second point of contact to lock the action down for maximum rigidity and repeatability.

FULL LENGTH DOVE TAIL RAIL: This is a game changer. Now you can mount Arca-Style Bipods & Tripods anywhere along the bottom of the rail giving you greater stability to make the shot.

MLOK® COMPATIBLE: .Magpul designed, U.S. Military mandated. The MLOK® attachment system won top spot in the Crane Report. MLOK® you to mount picatinny, night vision, illumination and/or grip panels as needed.

AMBIDEXTROUS: Adjustable & rotating aluminum thumb rest with knurled texture - add one to each side (four holes per side on chassis for mounting).

KNURLED BOTTOM PLATE: Our unique cross hatch knurling pattern runs along the bottom to provide additional grip when shooting off a bag or barricade.

INTEGRATED GRIP HANGER: Compatible with non-beavertail AR-style pistol grips (integrated design, not bolt-on).

BUTTSTOCK COMPATABLE: AR-15 buffer tube thread for buttstocks. With built-in set screw for no-castle nut style.

BULL BARREL CHANNEL: Up to a 1.25" barrel - factory to bull barrel.

ACCESSORY COMPATIBILITY: KIDD's rear tang compatible & Volquartsen Summit compatible. M-LOK slots, ARCA bottom, QD sling mounts, grip hanger, thumb rest all built in make mounting accessories clean and purposeful.

RIGIDITY & ZERO-FLEX: RPG Forends have incredible strength in a lightweight, no-flex form factor. All-6061 chassis and precise inlet design minimize flex/twist, boosting consistency and accuracy. KEEP IT TIGHT!!!

DURABLE FINISH: Every RPG part is finished in anodize or add ultra-durable Cerakote™ to resist wear and won't oxidize even in the harshest environments.

Material: 6061-T6 aluminum, CNC-machined
Finish: Type ll & III hard coat anodized, optional Cerakote
Manufactured: Built in the USA — designed and assembled in Evanston, Wyoming

Why is a Arca-Swiss Rail useful for precision rifle?

The Advantage of the Dovetail Rail

Often mis-referenced as “Arca-Swiss,” the 1.5” Dovetail Rail originated in the photography world. Arca-Swiss was the first company to develop a wide clamping rail system capable of securing large-format cameras on tripods.

Today, that same system is the standard in precision rifles. Integrated into the RPG Chassis, the Dovetail Rail lets you lock into tripods or bipods with speed and confidence, giving you a stable, repeatable platform no other system can match.

Why does the RPG include a Dovetail (Arca-Swiss) Rail?

Precision shooters adopted it because the wide, rectangular rail profile allows the rifle to sit flat in the clamp, preventing unwanted roll and increasing stability. When paired with a tripod or bipod, the Arca Rail delivers the fastest, most secure, and most adaptable shooting platform available — perfect for maintaining accuracy across uneven terrain or during quick position changes.

RPG CHASSIS ORDER NOW!

Weight by Configuration

SIMPLE, EFFECTIVE, AND BUILT FOR YOUR SHOOTING STYLE

The RPG provides a rigid, free-floating platform with integrated ARCA rails and modular forend choices. Whether you’re running NRL22, rimfire PRS, or building a dedicated trainer, the RPG delivers precision you can afford!

Weight by Configuration (with Glide Bar Brass Weights applied where noted):

Chassis + Comp Forend (16″) without weights: 33.1 oz (2 lbs 1.1 oz)
Chassis + Comp Forend (16″) with 1 Glide Bar (11.5 oz): ~44.6 oz
Chassis + Comp Forend (16″) with 2 Glide Bars: ~56.1 oz
Chassis + Comp Forend (16″) with 3 Glide Bars: ~67.6 oz
Chassis + Comp Forend (16″) with 4 Glide Bars: ~79.1 oz
Chassis + HR1 13″ Handguard + Adapter: 30.0 oz (1 lb 14 oz)
Chassis + HR1 16″ Handguard + Adapter: 37.6 oz (2 lbs 5.6 oz)
Chassis Inlet 10/22 Body Only: 15.1 oz
HR1 Adapter Only: 5.4 oz
Comp Forend (16″ standalone): 17.1 oz (1.07 lbs)

Note about an aluminum chassis: Aluminum is lightweight and stiff, but it has less mass. Less mass means more prone to vibrate (higher amplitude) unless damped or weighted. By adding brass weights, you increase overall mass, lower resonance amplitudes, and move the system’s vibration nodes. That means more consistent bullet exits relative to the vibration cycles (better grouping).

Why Use Glide Bar Brass Weights with the RPG Comp Forend?

RPG Chassis’s 16″ COMP Forend is made for shooters who want total control—balance, weight distribution, and vibration damping. Our Glide Bar Solid Brass Weights give you exactly that.

Each 11.5-oz bar inserts smoothly into the RPG COMP Forend (up to four bars), increasing mass in the front, reducing unwanted vibration, and helping maintain consistent harmonics shot after shot.

Because brass dampens vibration more effectively than steel or aluminum, they blend seamlessly with the aluminum chassis to improve group sizes and follow-up shot speed. Plus, they’re a drop-in replacement for the steel weights in many MDT chassis, so you can upgrade without remaking your whole build.

GLIDE BAR BRASS WEIGHTS ORDER NOW

Second Point of Contact — Why It Matters

Every precision shooter knows that consistency is everything. RPG includes a Steel Cone Screw

This steel screw applies controlled pressure directly to the trigger group, creating a second point of contact that locks the receiver firmly into the chassis. The result:

Zero movement of the action under recoil or during transport
Improved harmonics by reducing micro-shifts between the receiver and chassis
Repeatable accuracy every time you break down and reassemble your rifle

By pairing this system with the RPG’s rigid aluminum body, you get a level of bedding stability that rivals custom gunsmith work — built right into the chassis.

RPG CHASSIS FAQs / PLEASE READ

Does the RPG Chassis come with a buttstock?

No — you choose your own AR-15 buffer tube and stock to complete the build.

Which grips are compatible?

Any AR-style pistol grip without a beavertail.

Can I switch between forends later?

Yes — the RPG is modular. You can start with a Comp Forend and later move to HR1, or vice versa.

What does adding these brass weights actually do to accuracy?

More mass up front helps reduce the amplitude of barrel and fore-end vibration, shifts vibration nodes, and slows down resonant oscillation. The bullet exits at a more stable moment, giving tighter, more consistent grouping.

Will steel weights work too?

Yes, but steel tends to transmit vibration more than brass. You’ll get weight, but might lose some vibration dampening and consistency compared to brass. For precision use, brass tends to outperform.

Will adding this much weight affect handling?

Absolutely. More weight means slower transitions and a heavier front end. But for applications where stability and grouping are more important (NRL22, benchrest, prone), that trade-off is often worth it. The design of the RPG allows you to choose how many bars to use, so you can balance handling vs stability as needed.

What barrels will it fit?

The RPG includes a bull barrel channel and is compatible with Volquartsen Summit receivers and Kidd rear tang setups.

Will the MLOK® accessory screws touch the barrel?

You never want anything touching you barrel so our MLOK® accessories have shortened screws that allow clearance with even heavy barrels. Please note if you use some MLOK® accessories you may need to remove your handguard before removing your barrel. The Maxim Picatinny rails we offer here will not inhibit barrel removal.

Why is there a little slot cut into the HR1 by the receiver?

That little slot is a window to visually confirm that your barrel has been seated all the way into the receiver when you change it. ALWAYS LOOK AND CONFIRM THIS WHEN CHANGING YOUR BARREL.

What finishes are available?

The RPG anodized TYPE II & III or Cerakote

WHAT IS Coming Soon

New inlet options for CZ457, Bergara BMR, and Remington 700 (precision & hunter)
Additional forend systems, including RPG + HR15 handguard adapters
More finish and Cerakote color options
